R911335447 (CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 5 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911335447 (CSH01.1C-SE-EN2-EN2-NNN-S2-S-XP-FW) is a single-axis control section from the IndraDrive CSH series, designed for integration within automation systems such as those found in machine tools and food packaging equipment. This model incorporates a SERCOS master communication interface enabling real-time data transfer via fiber optic connection, which reduces electromagnetic interference. It provides two integrated encoder evaluation interfaces compatible with EnDat 2.1, 1 Vpp, and TTL encoders. The unit includes two analog outputs, a standard control panel for operational control and diagnostics, and Safe Motion for implementing safety functions. The power supply manages an inrush current of 4A with a maximum pulse width of 100 ms and supports operation with multiple switching frequencies.

Technical Specifications

Product Type
Configurable Single-Axis Control Section

Control Panel Display
Single-line

Safety Motion
Safe Motion

Inrush Current
4A

Max Pulse Width
100ms

Operational Switching Frequencies
2kHz, 4kHz, 8kHz, 12kHz, 16kHz

Cable Type
Fiber Optic

Application
Machine tools, Food packaging machines
