R911335498 (CSH01.1C-NN-ENS-MEM-MD2-NN-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 10 Seconds

The R911335498 (CSH01.1C-NN-ENS-MEM-MD2-NN-S-NN-FW) is a configurable control section designed for IndraDrive controllers, suitable for automation tasks such as handling and mounting systems as well as paper processing and printing machines. It integrates with a compatible power section, firmware, and control panel. The module features two analog outputs, digital I/O extension with SSI encoder interface, an IndraDyn encoder module, and does not include a master communication interface. It supports primary encoder options of Indradyn, Hiperface, 1 Vpp, or TTL. Installation requires connection of the control panel before activation, as hot swap is not supported. The power consumption is 7.5 W at 24 VDC input, with an inrush current of 4 A and a maximum pulse width of 100 ms.

Technical Specifications

Component of
IndraDrive Controllers

Mounting
Manual

Operating Conditions
As described in the product documentation

Configuration
Via a standard control panel

Hot Swap
Not supported

Power Consumption
7.5 Watts at 24 Volts DC input

Typical Inrush Current
4 Amps

Maximum Pulse Width
100 milliseconds
