R911335503 (CSH01.1C-SE-EN2-MEM-MA1-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN2-MEM-MA1-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911335503 (CSH01.1C-SE-EN2-MEM-MA1-L2-S-NN-FW) is a control section designed for integration with a drive controller, utilizing SERCOS as the primary master communication interface via X22 and X23 connections. This unit incorporates two analog outputs with I/O extension through the X10 connection. Dimensional specifications are 103 mm x 241 mm x 49.5 mm. The unit features an EnDat 2.1/1 Vpp/TTL encoder interface and includes a control panel equipped with a single-line display for monitoring operational values and system errors. A Safe Torque Off (SIL3/cat 3. PL e) function is available at connection point X41, supporting safety requirements. For optimal cooling, installation requires appropriate spacing for airflow. External power is necessary at X31.8 and X31.9. This control section is suitable for machine tools, printing and paper processing machines, and food machinery, and should be set up by qualified personnel.

Technical Specifications

Product Type
Control Section

Master Communication Interface
SERCOS

Physical Dimensions
103mm x 241mm x 49.5mm

Configuration
By engineer or trained technician

Display
Single-line display

Safety Feature
Safe Torque Off (SIL3/ cat 3. PL e)

Control Panel Interface Connection Point
H1

Serial Interface
Can be connected to X2 terminal

External Supply Voltage Points
X31.8 and X31.9
