R911335505 (CSH01.3C-PB-EN2-MA1-CCD-L2-S-NN-FW)

CSH Advanced Controllers

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911335505 (CSH01.3C-PB-EN2-MA1-CCD-L2-S-NN-FW) is a Bosch Rexroth control section engineered for complex drive and automation applications. Designed for integration into systems where operation is conducted by qualified personnel, it accommodates configurations with a single axis and supports a switching frequency as per system requirements. The unit incorporates 2 analog outputs, utilizes PROFIBUS for master communication, and supports EnDat 2.1, 1 Vpp, and TTL as primary encoder options. Digital I/O interfaces are available at X31.8 and X31.9, while the serial interface is accessed at point X2. The control section facilitates Safe Torque Off functionality, lacks support for bus wiring, and is to be installed in compliance with safety and accident prevention regulations. It should not be used near high-frequency equipment and direct contact during operation poses a burn hazard. Installation and removal actions should be minimized to preserve operational integrity, and the device is intended for use with proper sensors and actuators following a comprehensive system risk assessment.

Technical Specifications

Handling
Trained Personnel Only

Plug-in and Removal Actions
Limited

Additional Components
May Need Actuators and Sensors

Usage
Single-axis and Multi-axis Drive and Control tasks

Operation
Only under Assembly and Installation Conditions

Voltage Rating
More than 50V

Prevention from Unintentional Startup
Required

Operation Near High-frequency equipment
Not Allowed

Pacemaker Hazards
Possible

Risk Assessment
Required

Burn Hazards
Possible

Size
Smaller than Associated Power Section

Accident Prevention Regulations
Must Adhere

Dispatch
Worldwide

Pressure State during Dismounting
Not Allowed

Configurable
Yes

Number of Axes
Single

Switching Frequencies
Five Possible

Serial Interface Connection
X2 Connecting Point with Stranded Wire

Supply Voltage
External at X31.8 and X31.9 Connecting Points

Digital I/Os
Requires External Supply Voltage

Safety Technology
Supports Safe Torque Off with Optional Module

Bus Wiring Support
No

Backup Support
One Yea
