R911335698 (CSH01.3C-PB-ENS-EN1-CCD-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-ENS-EN1-CCD-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911335698 (CSH01.3C-PB-ENS-EN1-CCD-S2-S-NN-FW) is a digital control section for single-axis IndraDrive controllers, featuring IndraDyn and HSF/RSF encoder modules, a cross-communication module, and a safe motion safety module. Its operational power consumption is 8.5 W, with 6 W per encoder module, 2 W for the Profibus master communication module, and 1 W for the cross-communication module. The device includes two analog outputs, supports PROFIBUS master communication, and offers primary encoder interfaces for IndraDyn, Hiperface, 1 Vpp, or TTL signals. The control section includes two type plates for product identification, and connection points are available with spring or screw terminals. Firmware is not pre-installed and must be sourced separately. Installation and operation require trained personnel due to safety considerations.

Technical Specifications

Type
Digital Control Section

Category
Advanced Control Sections

Application
Single-Axis Applications

Control Panel Compatibility
Standard Control Panel

Firmware
Ordered Separately

Identification
Two Type Plates

Connection Points
Spring Terminals or Screw Terminals

Recommended Wire Size for Dual Connection
0.5 to 1 mm2 (Same Cross Section)

Installation and Operation Personnel Requirements
Proper Training and Experience

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.3C-PB-ENS-EN1-CCD-S2-S-NN-FW.

Exchange

Want to sell your CSH01.3C-PB-ENS-EN1-CCD-S2-S-NN-FW?
