CSH01.1C-PB-EN1-NNN-NNN-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911335904 (CSH01.1C-PB-EN1-NNN-NNN-L2-S-NN-FW) is a single-axis control section from the Rexroth Indramat CSH01.1C series, designed for use with MKD, MKE, and MHD motors. This model supports PROFIBUS master communication and integrates HSF/RSF encoder options, in addition to resolvers. It provides two analog outputs and features a standard control panel for status monitoring, error diagnosis, and drive address configuration. Safe Torque Off (STO) technology is implemented for safety, and the device includes connection points with both spring terminals and screw terminal blocks. A protective diode is present for polarity protection, and mounting cycles should not exceed 20.

Technical Specifications

Type
Single-axis Control Section

Master Communication
PROFIBUS Network

Module Equipped
Resolvers and Encoder Systems with HSF Interface

Power Supply Type for Encoder Systems
8V

Standard Control Panel
Yes

Display Type
Single-line

Safety Technology
Safe Torque Off

Accessory Compatibility Requirement
Rexroth Indramat Endorsed Parts

Firmware Operation
Reading, Storing, and Executing Data Transfer

Connection Points Type
Spring Terminals and Screw Terminal Blocks

Max Mounting and Dismounting Times
20 Times
