R911336313 (CSH01.1C-SE-EN1-ENS-NNN-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-SE-EN1-ENS-NNN-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth motion control component R911336313 (CSH01.1C-SE-EN1-ENS-NNN-S2-S-NN-FW) is equipped with S2 safe motion safety and requires separately ordered firmware. It incorporates a user control panel, SERCOS interface for master communication with a minimum cycle duration of 250 microseconds, and supports HSF/RSF encoder options on the X4 slot. The device features two analog outputs, four digital outputs, and eleven digital inputs. Electrical characteristics include 4 A inrush current and 7.5 W power consumption. The unit integrates a 1 W SERCOS module and a 6 W IndraDyn/hiperface encoder. Mechanical dimensions are 103 mm width, 49.5 mm depth, and 241 mm height. Operation and installation should be performed by qualified personnel.

Technical Specifications

Safety feature
S2 safe motion safety

Control Panel
Intuitive control panel

Encoder slot X4
HSF/RSF encoder

Minimum cycle duration
250 microseconds

Analog outputs
2

Digital outputs
4

Digital inputs
11

Inrush current
4 amps

Power consumption
7.5 watts

Communication module
SERCOS interface (1W required)

Option 2 (X8 slot) encoder
6 W IndraDyn/hiperface encoder

Width
103 mm

Depth
49.5mm

Height
241 mm

Single serial interface
Yes

Intended usage
Industrial
