R911336610 (CSH01.1C-PB-EN2-EN2-MEM-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN2-MEM-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911336610 (CSH01.1C-PB-EN2-EN2-MEM-L2-S-NN-FW) is an industrial automation controller module featuring a PROFIBUS communication interface and support for both Option 1 and Option 2 EnDat 2.1/1 Vpp/TTL encoders. The unit includes 11 digital inputs, 4 adjustable digital outputs, 1 analog input, and 2 analog outputs. Safety functions are enabled via the L2 safety option, and the device operates on a 24 VDC supply with a power consumption of 7.5 kW and a 4 A inrush current. Control cycle times are as follows: velocity (125–250 ms), current (62.5–125 ms), and position (250–500 ms). The relay contact can switch between 2 and 16 Hz, and the unit supports a minimum SERCOS cycle time of 250 ms depending on firmware, which is not included. Additional features are a 100 ms pulse width and integrated encoder emulator and standard control panel. Proper configuration for system safety is necessary.

Technical Specifications

Communication Module
PROFIBUS

Digital Inputs
11

Safety Option
L2

Velocity Control Range
125-250 milliseconds

Current Control Range
62.5-125 milliseconds

Position Control Range
250-500 milliseconds

Power Consumption
7.5 kW

Inrush Current
4 A

Encoder Option 1
EnDat2.1

Encoder Option 2
EnDat2.1

Power Supply
24-volt DC

Pulse Width
100 milliseconds

Relay Contacts
Single relay contact

Switching Frequency
2 to 16 Hz

Minimum SERCOS Cycle Time
250 milliseconds

Digital Outputs
4 adjustable outputs

Analog Inputs
1

Analog Outputs
2

Additional Features
Encoder emulator, Standard control panel.
