R911336645 (CSH01.1C-PB-EN2-EN2-NNN-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-EN2-NNN-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Indramat MPN R911336645 (CSH01.1C-PB-EN2-EN2-NNN-L2-S-NN-FW) is a control section designed for industrial automation systems. It features four programmable digital outputs, eleven digital inputs, one analog input, and two analog outputs. The unit supports PROFIBUS master communication and offers EnDat 2.1, 1 Vpp, or TTL encoder connectivity. Operating on a 24 V DC power supply, it has a maximum power consumption of 7.5 kW and an inrush current of 4 A. The module includes a standard control panel, a single relay contact, and may be equipped with an optional L2 safety module. SERCOS cycle times start at 250 ms. Firmware must be sourced separately.

Technical Specifications

Digital Outputs
4

Analog Input
1

Analog Outputs
2

Velocity Control Cycle Time
125-250 milliseconds

Current Control Cycle Time
62.5-125 milliseconds

Position Control Cycle Time
250-500 milliseconds

Power Consumption
7.5 kW

Inrush Current
4 A

Encoders
EnDat2.1

Pulse Width
100 milliseconds

Power Source
24-volt DC

Switching Frequency
2 to 16 Hz

Communication Module
PROFIBUS

Digital Inputs
11

Optional Safety Module
L2

Install and Operate
by a skilled technician

SERCOS Cycle Times
Starting at 250 milliseconds
