R911337214 (CSH01.3C-PB-EN1-EN2-CCD-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-EN1-EN2-CCD-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911337214 (CSH01.3C-PB-EN1-EN2-CCD-S2-S-NN-FW) is a single-axis control unit from the CSH series designed for integration into industrial automation systems, including applications such as packaging machinery and machine tools. This model features two analog outputs and supports master communication via PROFIBUS. It offers primary encoder compatibility with HSF/RSF signals and can accept 5V-TTL square-wave, sin-cos, and resolver encoders, supplying 5V or DC 8V/AC18.2V peak-to-peak as required. The unit supports switching frequencies from 2 kHz to 16 kHz and incorporates modules for cross communication within the drive system and safety I/O for implementing safe maximum speed and safe door locking functions. The control unit is firmware-compatible according to the specified configuration.

Technical Specifications

Product Line
Rexroth IndraDrive drive system

Product Type
Configurable single-axis control sections

Encoder Evaluation Interface Supply Voltage
5V

Communication Module
PROFIBUS

Safety Module
Safety Technology I/O

Switching Frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, and 16 kHz

Software
Firmware.

Common Misspellings

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CSH01.3C-PB-EN1-EN2-CCD-S2-S-NN-FW.

Exchange

Want to sell your CSH01.3C-PB-EN1-EN2-CCD-S2-S-NN-FW?
