R911337412 (CSH01.1C-PB-EN2-NNN-MA1-S2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN2-NNN-MA1-S2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911337412 (CSH01.1C-PB-EN2-NNN-MA1-S2-S-NN-FW) is an industrial controller module designed for motor control applications in automated systems. It incorporates two analog outputs, supports master communication via PROFIBUS, and provides primary encoder interfacing through EnDat 2.1, 1 Vpp, or TTL. The device operates within an IP20 housing, requires grounding prior to activation, and features a standard power consumption of approximately 7.5 W with an inrush current of 4 A and leakage current of 3.5 mA. All installation and operational guidelines must be strictly observed as specified in the technical documentation.

Technical Specifications

Producer
Rexroth Indramat

Usage
Control of Electrical Motors

Manufacturing Standards
American and European Standards

Housing Unit Design
IP20 Protection Class

Integration Requirement
Requires Integration into Power Control Unit

Communication Module
Profibus PB

Power Consumption
7.5 Watts

Inrush Current
4 Amperes

Leakage Current
3.5 Milliamperes

Grounding Requirement
Securely Connected to a Grounding System
