R911337413 (CSH01.1C-PB-ENS-MA1-MD2-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-ENS-MA1-MD2-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 34 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911337413 (CSH01.1C-PB-ENS-MA1-MD2-L2-S-NN-FW) is a Rexroth IndraDrive CSH01 controller module, featuring an integrated control and power section within its drive controller design. This module supports high-performance operation and dynamic response in applications such as food and paper processing or machine tools. It includes a standard encoder evaluation interface compatible with 12V encoder systems (e.g., sin-cos encoders with EnDat 2.1) and 5V-TTL square-wave encoders with reference track. The device is equipped with a Digital I/O extension supporting 16 inputs and outputs and provides absolute position detection for SSI-interface encoders. It features 2 analog outputs, PROFIBUS for master communication, and primary encoder options including Indradyn, Hiperface, 1 Vpp, and TTL. Remote commissioning can be performed via IndraWorks software or the integrated one-line display control panel.

Technical Specifications

Rexroth Line
IndraDrive

Type
Control Section

Usage
Single-Axis Control

Range
ADVANCED Control Section

Size
Compact

Remount value
20 Times

Supply Voltage for Encoder System
12V

Digital I/O extension
16 inputs and 16 outputs

Control Panel Display
Single-Line.
