R911339619 (CSH01.1C-S3-EN1-EN2-NNN-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-S3-EN1-EN2-NNN-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911339619 (CSH01.1C-S3-EN1-EN2-NNN-L2-S-NN-FW) is a control section for drive systems, equipped with SERCOS III master communication and a configurable pulse-width modulation frequency between 2 and 16 kHz. It includes one RS232 serial port, four digital outputs, two analog outputs, one analog input, and supports both RSF/HSF and EnDat2.1 encoder interfaces. The unit offers the L2 safety option and should be operated exclusively with compatible drive controllers and within prescribed environmental parameters to ensure correct performance. Firmware must be procured separately.

Technical Specifications

Product Type
Electric Drives and Control Systems

Serial Port
Single RS232

SERCOS Cycle Duration
250 microseconds

Digital Outputs
4

Current Control Range
62.5 to 125 microseconds

Position Control Range
250 to 500 microseconds

Control Panel Power Consumption
1 Watt

Drive Power
Varying

Interfaces
Application-specific

Digital Outputs (for application tasks)
4

Analog Inputs (for application tasks)
1

PWM Frequency
2 to 16 kHz (changeable)

Encoder (X8 Slot)
EnDat2.1

Safety Option
L2 (Safe Torque Off)

Encoder (X4 Slot)
6-Watt RSF/HSF

Operational Conditions
Specific Ambient Conditions
