R911339738 (CSH01.3C-PB-EN2-MEM-CCD-NN-S-NN-FW)

CSH Advanced Controllers

CSH01.3C-PB-EN2-MEM-CCD-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911339738 (CSH01.3C-PB-EN2-MEM-CCD-NN-S-NN-FW) control section from Bosch Rexroth features compact dimensions of 241 x 103 x 49.5 mm. It integrates encoder emulation capabilities via the MEM module, supporting two differential analog input channels at 12-bit resolution with ±10V, provided by the MA1 module. Encoder signals are generated without requiring an external power source, and connections are managed through a 15-pole D-Sub female connector for MA1, alongside screw and spring terminals. It offers two Type 2 probe inputs, analog outputs, and supports PROFIBUS for master communication. Safety functions include safe stop and safe communication. Power is supplied through 0V and 24V terminal connectors. The primary encoder option is EnDat 2.1/1 Vpp/TTL. Device surfaces may become hot during operation.

Technical Specifications

Interface Encoder Emulation
Supported

External Power Supply
Not Needed

Product Size
241 x 103 x 49.5mm

Memory Card Slot
Available

Type 2 Probe Inputs
2

D-Sub Female Connector
15 poles

Backup Support
1 year

Power Consumption
Consideration of control panel and multimedia card

Connection Points
Screw terminal blocks and spring terminals

Signal-level Converter
HAS05.1-003

Eco-friendly Materials
Used

Monitoring Functions
Incorporated

Surface Temperature
High during and after operation

Transportation
Custom military-grade packaging.
