The Bosch Rexroth MPN R911342755 (CSH01.3C-PB-EN2-EN2-CCD-L2-S-NN-FW) is a single-axis IndraDrive system integrating both power and CSH control sections. The CSH section is compatible with multiple encoder types, including sin-cos 1 Vpp with EnDat 2.1, supporting a 5V supply with sense lines. It features two communication modules: PROFIBUS and an IEEE 802.3 cross communication module, both equipped with status LEDs for state indication. The device supports two analog outputs, frequency operation between 2 kHz and 16 kHz, and a maximum pulse width of 100 ms with a typical inrush current of 4 A, compliant to IEC 61800‑3 category C3. Terminal connections include both spring and screw terminal blocks for vibration-resistant installation.

Technical Specifications

Product Type
CSH Control Section

Range Category
ADVANCED

Encoder Evaluation Interfaces
2

Communication Module Type
PROFIBUS

Additional Communication Module
Yes, corresponding to the IEEE 802.3 standard

Operating Frequencies
2 kHz, 4 kHz, 8 kHz, 12 kHz, 16 kHz

Typical Inrush Current
4A

Maximum Pulse Width
100ms

Compliance Category
C3 (per IEC 61800‑3)

Suited Location
Industrial Areas

Electrical Connectors
Spring Terminals and Screw Terminal Blocks.
