R911344976 (CSH01.1C-PB-EN1-NNN-MD2-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-PB-EN1-NNN-MD2-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Indramat MPN R911344976 (CSH01.1C-PB-EN1-NNN-MD2-L2-S-NN-FW) is a CSH series control system equipped with a safety module supporting the Safe Torque Off function via a D-sub 9-pin female interface, compatible with copper wire from 0.25 to 0.5 mm². The digital Input/Output extension includes an SSI encoder interface, providing 16 digital inputs and 16 outputs, with maximum line lengths up to 75 meters depending on the SSI clock frequency, reduced to 40 meters at 1000 kHz. An adapter cable is used for the SSI encoder connection. The unit incorporates an encoder module for compatibility with motors featuring resolver or digital servo feedback (HSF/RSF). PROFIBUS is used for master communication, and active terminators are necessary for network operation. The control section must be mounted to a power section if supplied separately. Two analog outputs are integrated into the design.

Technical Specifications

Optional Modules Installed
Yes

Safety Module Support
Safe torque off function

Safety Module Interface
D-sub 9-pin female

Digital I/O Extension Module Support
16 digital outputs and 16 digital inputs

Galvanic Isolation
Present

Digital I/O Interface
D-sub high density interface with 44 pins

SSI Encoder Interface
RJ12 interface with 6 pins

Max Line Length at 125 / 250 / 500 kHz
75 meters

Max Line Length at 1000 kHz
40 meters

Third Installed Module
Encoder HSF / RSF module

Communication Support
Profibus master
