R911369673 (CSH01.1C-ET-EN2-EN2-NNN-L2-S-NN-FW)

CSH Advanced Controllers

CSH01.1C-ET-EN2-EN2-NNN-L2-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911369673 (CSH01.1C-ET-EN2-EN2-NNN-L2-S-NN-FW) is a configurable control section featuring a MultiEthernet master communication interface and integrated safe torque off technology. It incorporates two analog outputs, supports primary encoders with EnDat 2.1, 1 Vpp, or TTL signal formats, and includes one analog input. The unit is equipped with a standard control panel for system parameter monitoring and management. Suitable for environments with ambient temperatures up to +40°C and maximum humidity of 90% non-condensing, it maintains a continuous operational power loss of 7.5 W. Installation and operation require qualified personnel following the provided technical user documentation.

Technical Specifications

Product type
Advanced Control Section

Communication interface
MultiEthernet

Additional Features
Safe Torque Off Technology

Operating Environment
Dust- and water-free

Control Panel
Standard

Allowable Operating Temperature
Up to +40 degrees Celsius

Peak Humidity Without Condensation
90%

Power loss during Continuous Operation
7.5 W

Number of Analog Inputs
One

Operating Frequencies
2, 4, 8, 12, 16 kHz

Cooling Mechanism
Natural Convection
