The Bosch Rexroth MPN R911391169 (CSH01.1C-S3-EN1-EN1-NNN-L2-S-NN-FW) is a single-axis drive controller featuring the CSH01.1 control section. It supports SERCOS III as the master communication protocol, provides two analog outputs, and is equipped with an HSF/RSF primary encoder option in the X4 and X8 slots. The device has 11 digital inputs, a single RS232 interface, and includes an L2 safety function. Power consumption is 7.5 W for the main unit and 6 W for the encoder, with an inrush current of 4 A. The unit measures 241 mm × 103 mm × 49.5 mm. Operation must comply with temperature, humidity, and attachment guidelines specified in the user manual for optimal performance.

Technical Specifications

Inrush Current
4 A

Power Consumption
7.5 W

Safety Function
L2 (safe torque off)

Control Panel Power
1 W

Digital Inputs
11

Encoder
HSF/RSF

Encoder Power
6 W

Communication Module
SERCOS 3

Communication Module Power
1 W

Interface
RS232

Dimensions
241mm x 103mm x 49.5mm

Motion Logic Standards
IEC compliant
