R911329659 (HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW)

HCQ Micro Controls

HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911329659 (HCQ02.1E-W0025-A-03-B-L8-1S-D1-NN-NN-FW) is a converter-type drive controller designed for position and speed regulation across four axes in industrial automation systems. It provides support for five encoder evaluations, 16 digital outputs, and 32 digital inputs. The unit interfaces via LVDS and USB, and can connect to an embedded PC for master communication. The controller operates on a three-phase mains supply of 200–500 V, with a rated power of 25 kW, and utilizes an external braking resistor for motor control. Forced ventilation is implemented for thermal management. It is intended for installation in environments with ambient temperatures up to 40°C and at elevations not exceeding 1000 meters. Physical parameters include a mass of 11.7 kg and a flat-type design.

Technical Specifications

Product Type
Drive Controller

Usage
Position and Speed Control

Type
Converter

Number of Axes
4

Construction
Flat Type

Encoder Evaluations
5

Interface
Operator Panel (LVDS + USB)

Braking System
External Braking Resistor

Operating Voltage
200 V - 500 V

Weight
11.7 kg

Ventilation
Forced

Connectivity
Sercos III Master Port and EtherNet Port

Digital Outputs
16

Digital Inputs
32

Operating Current
44 A

Maximum Installation Height
1000 m

Ambient Temperature for Operation
up to 40 ᵒC
