The Bosch Rexroth 1070170289 (MPN: PPC-R22.1N-T-Q1-V2-NN-FW) is an industrial motion and logic control unit designed for robotics and multi-axis motion control. It operates within the VisualMotion 10 range and supports VisualMotion GPP 10 firmware for integrated logic and motion tasks. The unit interfaces with Reco 02 racks, EcoDrive 03 digital servo drives, and IndraDrive Diax 04 drives. Features include a fiber optic SERCOS interface for real-time drive communication, an Ethernet interface supporting TCP/IP and Ethernet/IP fieldbus slave functions, and dual serial ports. It incorporates a DeviceNet fieldbus slave module (DNS03) and supports cross-communication and DAQ03. Housed as a RECO unit, it lacks memory expansion and is specified for 24 VDC operation (rated value), accepting supply voltages from 19.2 to 30 VDC with a ripple factor included and tolerance of -15% to +20% (EN61131-2:1994). Power consumption is up to 1.2 A at 24 VDC. Dimensions are 184 x 8 x 165 mm, and the weight is 2.87 lbs.

Technical Specifications

Application
Industrial, Robotics, Multi-axis motion control

Product Type
Motion and Logic Control System

Product Range
VisualMotion 10

Firmware
VisualMotion GPP 10

Compatible Racks
Reco 02

Additional Modules
DeviceNet slave module

Memory Expansion
Not supported

Weight
2.87 lbs

Dimensions
184 x 8 x 165 millimeters

Enclosure Rating
IP20

Power Requirement
Max 1.2 Amps at 24 Volts DC

Frequently Asked Questions

What is the communication type of PPC-R22.1N-T-Q1-V2-NN-FW?

The PPC-R22.1N-T-Q1-V2-NN-FW supports Cross Communication and DAQ03.

Which fieldbus interface is used in PPC-R22.1N-T-Q1-V2-NN-FW?

The PPC-R22.1N-T-Q1-V2-NN-FW has a DeviceNet fieldbus slave interface (DNS03).

What is the housing design of PPC-R22.1N-T-Q1-V2-NN-FW?

The PPC-R22.1N-T-Q1-V2-NN-FW is designed with a RECO unit housing.

What is the rated voltage of PPC-R22.1N-T-Q1-V2-NN-FW?

The PPC-R22.1N-T-Q1-V2-NN-FW operates at 24 VDC.

Does PPC-R22.1N-T-Q1-V2-NN-FW have memory expansion?

No, the PPC-R22.1N-T-Q1-V2-NN-FW is not equipped with memory expansion.

Common Misspellings

PPC R22.1N-T-Q1-V2-NN-FW

PPC.R22.1N-T-Q1-V2-NN-FW

PPCR22.1N-T-Q1-V2-NN-FW

PPCR221NTQ1V2NNFW

PPC R22 1N T Q1 V2 NN FW

ppc-r22.1n-t-q1-v2-nn-fw

PPCR22.1NTQ1V2NNFW

PPC R22.1N T Q1 V2 NN FW

Internal Product Review

The PPC-R22.1N-T-Q1-V2-NN-FW delivers stable DeviceNet communication with cross-communication capabilities. Its compact design and wide voltage tolerance provide a practical solution for industrial automation requiring long-term reliability.
