The Bosch Rexroth MPN R911310248 (PPC-R22.1N-T-Q1-P1-P2-FW) is a standalone, multi-axis motion and logic control unit designed for integration with up to 40 Rexroth digital drives, including EcoDrive 03 and Diax 04. It supports a control interface via PC-operated VisualMotion Toolkit and requires GPP10 firmware for multi-axis motion functionality. The device features Ethernet and ARCNET communication, a Serco interface with selectable baud rates, two serial ports, and two PROFIBUS-DP Fieldbus interfaces for Master and Slave operation. It includes a 4-digit alphanumeric display and does not provide onboard memory expansion. Communication capabilities include cross communication and DAQ03, housed in a RECO unit with design version 1. The permissible input range is 19.2 to 30 VDC (ripple factor included), rated at 24 VDC, with -15% to +20% tolerance per EN61131-2:1994. Physical specifications: 164 mm height, 165 mm depth, 84 mm width, 2.87 lb weight. Operating temperature range is 32 to 113°F with humidity between 5% and 78%; storage temperature is -13 to 158°F, and operational altitude is supported up to 3,000 meters.

Technical Specifications

Form Factor
Reco 02

Maximum Drives Supported
40

Programming Software
VisualMotion Toolkit

Compatible Firmware
GPP10

Motion Control Supported
Multi-axis coordinated and non-coordinated

Onboard Ethernet
Yes

ARCNET Support
Yes

Display
4-digit alphanumeric

Serco Interface
2 / 4/ 8 / 16 Mbaud

Serial Interface Ports
Two

Baud Rate
9600 to 115200

Memory Expansion
Not available

Installation
Slot 00 of the Reco 02 rack

Dimensions (H x D x W)
164 x 165 x 84 millimeters

Weight
2.87 pounds

Operating Temperature
32-113 degrees Fahrenheit

Storage Temperature
-13 to 158 degrees Fahrenheit

Operating Relative Humidity
5 to 78%

Non-operating Relative Humidity
5 to 95%

Maximum Operating Altitude
1500 meters

Atmospheric Range
860 to 1080 hPa

Storage Altitude
Up to 3000 meters

Frequently Asked Questions

What is the communication type of PPC-R22.1N-T-Q1-P1-P2-FW?

The PPC-R22.1N-T-Q1-P1-P2-FW controller supports Cross Communication and DAQ03.

Which fieldbus interface is used in PPC-R22.1N-T-Q1-P1-P2-FW?

The PPC-R22.1N-T-Q1-P1-P2-FW uses a Profibus fieldbus slave interface (DPS01).

What is the housing design of PPC-R22.1N-T-Q1-P1-P2-FW?

The PPC-R22.1N-T-Q1-P1-P2-FW has a RECO unit housing design.

Does PPC-R22.1N-T-Q1-P1-P2-FW have memory expansion?

No, the PPC-R22.1N-T-Q1-P1-P2-FW is not equipped with memory expansion.

What is the permissible supply voltage range of PPC-R22.1N-T-Q1-P1-P2-FW?

The PPC-R22.1N-T-Q1-P1-P2-FW operates within a range of 19.2 … 30 VDC.
