VT-HNC100-1-2X-W-08-S-0

Name: VT-HNC100-1-2X-W-08-S-0
Brand: Indramat Controls
SKU: VT-HNC100-1-2X-W-08-S-0
Price: 321.00 USD
Availability: InStock

VT-HNC Digital Axis Controllers

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The VT-HNC100-1-2X-W-08-S-0 is a digital axis control model from Bosch Rexroth, renowned for its premium quality. It features two inductive position transducers with an optional PROFIBUS serial interface and a grey code SSI transducer, and operates at a maximum current of 30 milliamperes per channel with a 2-volt power supply. The device runs on a 16/32-bit MC68376 processor and must function within a temperature range of 0 to +50 degrees Celsius. Offering an operating voltage range of 18 to 36 VDC, it's intended for integration into systems or machinery. Its purpose is to manage the position, pressure, force, and speed of hydraulic axes within machinery. The model, devoid of personal safety features, includes 1 MB of EPROM, 8 KB of EEPROM, and 256 KB of RAM. It weighs 1kg, with dimensions of 71 x 155 x 204, and offers four analog voltage outputs, a +10 mA output current, and a 1 Kohm load. The model includes four analog current inputs with an input resistance of 100 ohms, and 0.1 to 0.4 percent power loss. The VT-HNC100-1-2X-W-08-S-0, compliant with EC guidelines, is distributed globally by Indramat USA, ensuring all requirements for managing hydraulic and electrical drives are met.
