CDB01.1C-PB-EN1-EN1-EN2-EN2-L1-S-NN-FW

CDB Control Units

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

CDB01.1C-PB-EN1-EN1-EN2-EN2-L1-S-NN-FW, Bosch Rexroth Indramat, CDB Control Units opens with a PROFIBUS master communication backbone that delivers high-speed deterministic control. The CDB01.1C-PB-EN1-EN1-EN2-EN2-L1-S-NN-FW integrates seamlessly into the CDB Control Units series, leveraging Bosch Rexroth’s proven motion-control architecture. This control section features redundant encoder ports and advanced interface options to maximize flexibility. Designed for precise synchronization, it supports real-time data exchange and simplifies multi-axis coordination.



In-depth specifications include Master Communication: PROFIBUS, dual Option 1: Encoder HSF/RSF ports at X4.1/X4.2, dual Option 2: Encoder HSF/RSF for hot-swap redundancy, and dual Option 3: Encoder EnDat 2.1/1Vpp/TLL at X8.1/X8.2. The unit’s Cooling Requirement: sufficient ventilation gap on sides and top mitigates thermal buildup during continuous operation. A Warranty Period: one-year from Wake Industrial guarantees long-term confidence. Safety is enforced via a Safety Feature: starting lockout, preventing unintended startups during maintenance. Operational feedback is delivered through a Display Type: single-line control panel, and Navigation Keys enable on-the-fly parameter adjustments.



Engineers benefit from plug-and-play integration with the Rexroth drive ecosystem, ensuring deterministic timing and minimal latency for high-performance applications. Robust design and conformal-coated electronics deliver proven reliability in industrial environments. The CDB01.1C-PB-EN1-EN1-EN2-EN2-L1-S-NN-FW excels in complex, multi-axis motion systems requiring precise encoder feedback and safe, uninterrupted operation.

Technical Specifications

Master Communication
PROFIBUS

Option 1
Encoder HSF/RSF

Option 2
Encoder HSF/RSF

Option 3
Encoder EnDat 2.1/1Vpp/TLL

Common Misspellings

Shipping & Payment Options
DHL-logo FexEd-logo UPS-logo freight-icon

AmEx-icon Mastercard-icon Visa-icon wire-transfer-icon
Warranty
1-year-warranty
Indramat USA 1 Year Warranty
Repair
product repair We offer a repair service for the CDB01.1C-PB-EN1-EN1-EN2-EN2-L1-S-NN-FW.
