CDB01.1C-PB-EN1-EN1-NNN-MEM-L1-S-NN-FW

The Bosch Rexroth Indramat CDB01.1C-PB-EN1-EN1-NNN-MEM-L1-S-NN-FW from the CDB Control Units series supports dual-axis control with a Master Communication PROFIBUS interface and Encoder HSF/RSF options on both channels. This control unit features a design code 1 and is rated for a typical inrush current of 6 A, ensuring robust startup performance. It can be mounted and dismounted up to 20 times without performance degradation, making maintenance and reconfiguration straightforward. The module’s power consumption is determined by its base equipment and any optional modules installed.

Connectivity and protection features include a +5 V repeater supply output on the PROFIBUS module, complete with a connectable terminating resistor at both the first and last nodes. External supply for digital inputs and outputs is provided via the X31.8 and X31.9 connectors, while power arrives through 0 V and 24 V terminals. Internal protective diode circuitry guards against polarity reversal and incorrect supply connections. For signal wiring, the control unit requires TWIN ferrules and stranded wires with a cross-section between 0.5 mm2 and 1 mm2 per conductor, ensuring secure, low-impedance connections at each terminal.

Built for industrial environments, the CDB01.1C is shipped only in conductive packaging to prevent electrostatic damage and must never be operated if damaged or outside manufacturer guidelines. This control section is intended exclusively for its designed automation applications and carries a one-year Wake Industrial warranty. With straightforward PROFIBUS integration, dual Encoder HSF/RSF options, and robust electrical protection, the CDB01.1C-PB-EN1-EN1-NNN-MEM-L1-S-NN-FW provides reliable, high-performance motion control for complex multi-axis systems.
