CDB01.1C-PB-ENS-ENS-ENS-ENS-NN-S-NN-FW

CDB Control Units

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 2 Seconds

CDB01.1C-PB-ENS-ENS-ENS-ENS-NN-S-NN-FW, Bosch Rexroth Indramat, CDB Control Units deliver precision drive management in a compact footprint. The CDB01.1C-PB-ENS-ENS-ENS-ENS-NN-S-NN-FW module from Bosch Rexroth Indramat’s CDB Control Units line features integrated PROFIBUS networking and advanced encoder interfaces. Engineered for automated drive systems, the unit supports configurable control sections and heavy-duty servo motors within minimal panel space. Its rugged design ensures high-density operation across varied industrial applications.



Detailed specifications include Master Communication: PROFIBUS for deterministic fieldbus integration and three distinct encoder interface options labeled Option 1: Encoder Indradyn/Hiperface/1 Vpp/TLL, Option 2: Encoder Indradyn/Hiperface/1 Vpp/TLL, and Option 3: Encoder Indradyn/Hiperface/1 Vpp/TLL. The control section measures 103 mm x 241 mm x 49.5 mm, allowing installations in constrained cabinets or modular groups. It accommodates both natural and forced convection cooling without additional hardware. Digital and analog I/O ports plus a relay output connection deliver versatile signal handling. The firmware-driven architecture enables current, position, and speed control with microsecond-level resolution and adjustable PWM frequency.



Integration into existing motion systems is seamless when following the Bosch Rexroth commissioning guidelines, and a protective diode safeguards against polarity errors. The space-saving CDB01.1C-PB-ENS-ENS-ENS-ENS-NN-S-NN-FW ensures reliable control under continuous industrial duty. Backed by a one-year warranty, this unit offers robust performance and simplified serviceability for conveyors, handling systems, and chemical process automation.

Technical Specifications

Master Communication
PROFIBUS

Option 1
Encoder Indradyn/Hiperface/1 Vpp/TLL

Option 2
Encoder Indradyn/Hiperface/1 Vpp/TLL

Option 3
Encoder Indradyn/Hiperface/1 Vpp/TLL
