CDB01.1C-SE-EN1-EN1-EN2-EN2-S2-S-NN-FW

The Bosch Rexroth Indramat CDB01.1C-SE-EN1-EN1-EN2-EN2-S2-S-NN-FW control unit is part of the CDB Control Units series, designed for precise digital control in double-axis applications. It features a SERCOS Interface for master communication and supports multiple encoder options including Encoder HSF/RSF and Encoder EnDat 2.1/1Vpp/TLL. This modular unit provides front-panel slots for configurable encoder modules, enabling integration with both analog resolver and digital encoder motor systems.

The CDB01.1C-SE-EN1-EN1-EN2-EN2-S2-S-NN-FW offers detailed technical flexibility through its four encoder module slots. Slots 1 and 2 each host an Encoder HSF/RSF module, optimized for motor encoder systems operating at 8 VDC or 18.2 VAC peak-to-peak. Slots 3 and 4 accommodate Encoder EnDat 2.1 modules, compatible with 5 VDC encoder signals. Each module connects via a female 15-pin D-sub interface, supporting stranded copper conductors from 0.25 to 1.0 mm2. The use of standardized D-sub connectors ensures reliable signal transmission and simplifies system wiring.

Beyond its core communication and encoder interfaces, this control section is tailored for high compatibility and efficiency in industrial automation. The SERCOS master interface conforms to real-time serial communication standards, supporting data rates from 2 to 100 Mbps in a ring topology. The modular design allows quick reconfiguration for different motor and feedback requirements, enhancing system uptime and reducing maintenance. By consolidating multiple encoder types and a high-speed communication interface in one front-accessible unit, the CDB01.1C-SE-EN1-EN1-EN2-EN2-S2-S-NN-FW delivers streamlined integration and robust performance for modern motion control environments.
