The Bosch Rexroth Indramat CDB01.1C-SE-EN2-EN2-EN2-EN2-S1-S-NN-FW control unit, part of the CDB Control Units series, leverages a SERCOS Interface for master communication and features four identical encoder evaluation interfaces configured for EnDat 2.1/1Vpp/TLL signals. As a double-axis control section in the Rexroth IndraDrive system, this configurable Version 1 model is designed to manage precision motion in handling and mounting systems as well as sophisticated machine tools. The unit’s primary application is to serve as the control section that plugs into a corresponding power section, providing high-performance drive control in compact assemblies.
In terms of detailed specifications, the CDB01.1C-SE-EN2-EN2-EN2-EN2-S1-S-NN-FW supports up to four sin-cos encoder connections, each supplying 5 V for both EnDat 2.1 and 1 Vpp/TLL square-wave signals, including reference track and Sense lines. The master communication module operates over fiber optics cables (ordered separately) to ensure robust, high-speed data transfer and electromagnetic immunity. As a compact double-axis device within the BASIC UNIVERSAL control section range, it provides streamlined integration, low-latency control loops, and consistent encoder evaluation for precise positioning and velocity feedback.
Additional design features emphasize both durability and ease of maintenance. The control section’s compact size allows simple mounting and dismounting, with a maximum of 20 plug-in cycles recommended to preserve connector integrity. A built-in standard control panel with a single-line display and four keys enables on-site adjustment of transmission power and bus transfer rates without auxiliary tools. The integrated Safety Technology I/O option supports safety-related functions such as reduced speed and drive interlock, conforming to application-specific safety standards. Shipped globally with a one-year warranty from Wake Industrial, this control unit delivers reliable, efficient performance and versatile compatibility for demanding industrial automation environments.
Master Communication
SERCOS Interface
Option 1
Encoder EnDat 2.1/1Vpp/TLL
Option 2
Encoder EnDat 2.1/1Vpp/TLL
Option 3
Encoder EnDat 2.1/1Vpp/TLL
