CDB01.1C-SE-ENS-ENS-EN1-NNN-S1-S-NN-FW, Bosch Rexroth Indramat, CDB Control Units deliver dual-axis precision in a single module, combining two digital control axes with a compact footprint. The CDB01.1C-SE-ENS-ENS-EN1-NNN-S1-S-NN-FW features an integrated Master Communication channel via SERCOS Interface for deterministic real-time performance, supported by visible LED indicators that report link status and fault conditions. As part of the renowned CDB Control Units series, it is engineered for seamless integration into the Rexroth IndraDrive ecosystem and offers field-proven reliability in machine tool and robotics applications. With user-configurable firmware loaded into non-volatile memory, commissioning is simplified and repeatable across multiple axes.

Paragraph-2 concentrates on the module’s rich array of connectivity and encoder evaluation. It supports two identical Option 1 and Option 2 ports for Encoder Indradyn/Hiperface/1 Vpp/TLL signals, plus a dedicated Option 3 interface for high-speed feedback with HSF/RSF encoders. Resolver inputs accept DC 8 V or AC 18.2 Vpp excitation, enabling legacy and high-resolution rotor position sensing in one unit. Control wiring attaches to spring-loaded terminals and screw terminal blocks, ensuring vibration-resistant connections without additional hardware. Configuration and diagnostics are accessible via the single-line single-line display on the built-in control panel, or through the IndraWorks PC software for parameter cloning and advanced monitoring. The unit conforms to category C3 per IEC 61800-3 for industrial electromagnetic compatibility.

In practice, the Bosch Rexroth Indramat CDB01.1C-SE-ENS-ENS-EN1-NNN-S1-S-NN-FW reduces cabinet complexity by replacing two separate drives with one double-axis control section, streamlining wiring and space requirements. Its robust SERCOS III interface and redundant encoder evaluations deliver deterministic motion with built-in fault detection, improving uptime in high-duty-cycle milling, turning, and pick-and-place lines. Certified for global shipping with a one-year warranty, this control section brings reliable performance and scalable integration to demanding automation environments.
