CDB01.1C-SE-ENS-ENS-MEM-MA1-L2-S-NN-FW

CDB Control Units

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat CDB01.1C-SE-ENS-ENS-MEM-MA1-L2-S-NN-FW from the CDB Control Units series features a Master Communication: SERCOS Interface and versatile encoder support including Encoder Indradyn/Hiperface/1 Vpp/TLL on Option 1 and Option 2, plus an Encoder Emulator on Option 3. This double-axis control section is part of the BASIC UNIVERSAL range and offers high-speed serial data transfer via fibre optic cables for secure link-up to higher-level controllers. Designed for industrial automation, the unit integrates a configurable control section architecture to adapt to diverse drive applications and motor types. With its embedded encoder evaluation interface, the control unit processes sin-cos, absolute, and incremental signals without requiring extra power supplies.



The CDB01.1C control module includes an Analog I/O extension to expand analog channel capacity, while Safe Torque Off (STO) functionality ensures operator safety by disabling torque generation during maintenance. The built-in standard control panel provides a single-line display and 4 keys for accessing error memory, setting drive addresses, and defining analog input ranges. Engineers can also establish the motor’s reference position directly from the panel, streamlining commissioning tasks without external tools. Note that the control panel is not designed for hot-plug operation and must only be connected or removed when the drive controller is powered down.



The robust design of the CDB01.1C-SE-ENS-ENS-MEM-MA1-L2-S-NN-FW ensures long-term reliability in demanding environments, and global shipping is supported with a one-year warranty period from Wake Industrial. This compact, feature-rich control unit is ideal for multi-axis systems where precise encoder handling, safety integration, and flexible I/O expansion are critical to achieving efficient automation performance.

Technical Specifications

Master Communication
SERCOS Interface

Option 1
Encoder Indradyn/Hiperface/1 Vpp/TLL

Option 2
Encoder Indradyn/Hiperface/1 Vpp/TLL

Option 3
Encoder Emulator
