The Bosch Rexroth Indramat CDB01.1C-SE-ENS-ENS-NNN-MEM-NN-S-NN-FW is part of the CDB Control Units series and features a robust Master Communication: SERCOS Interface for synchronized drive control. This unit integrates dual encoder interfaces with Option 1: Encoder Indradyn/Hiperface/1 Vpp/TLL and Option 2: Encoder Indradyn/Hiperface/1 Vpp/TLL in addition to a third slot marked Option 3: Not Equipped for optional expansion. Designed for high-end motion applications, it controls two axes concurrently and accommodates multiple safety and technology functions. The control unit is supplied with a universal adapter (HAS05.1-007) for safety technology and a built-in converter for encoder emulation.
The drive controller operates over multiple Switching Frequencies: 2 Hz, 4 Hz, 8 Hz to suit varying dynamic requirements and delivers reliable I/O performance with Digital Inputs: 4 and up to Digital Outputs: 18. Its electrical characteristics include a Power Consumption: 9 W, a Pulse Width: 60 ms and an Inrush Current: 6 A ensuring rapid startup without compromising stability. Performance optimization is achieved through the optional Interfaces: S3 sercos, CANopen, DeviceNet and an exceptionally Cycle Time: short for velocity, position, and speed control loops. Two separate safety technology slots safeguard functional integrity under demanding operating conditions.
Maintenance and commissioning are streamlined by a dedicated MMC slot for storing firmware and drive parameters, while the user-friendly Standard Control Panel simplifies local configuration. Multiple encoder standards—1 Vpp, TLL, and Indradyn—are natively supported to match existing machine setups. Backed by Bosch Rexroth Indramat’s proven engineering and Wake Industrial’s one-year warranty, this control unit is ideally suited for handling machines, printing systems, paper-processing lines, machine tools, and food production equipment.
Master Communication
SERCOS Interface
Option 1
Encoder Indradyn/Hiperface/1 Vpp/TLL
Option 2
Encoder Indradyn/Hiperface/1 Vpp/TLL
Option 3
Not Equipped
