R911305761 (CDB01.1C-SE-ENS-EN1-EN2-NNN-L1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN1-EN2-NNN-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 17 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911305761 (CDB01.1C-SE-ENS-EN1-EN2-NNN-L1-S-NN-FW) is a control section designed for integration into drive controllers within motion control and automation environments such as machine tools, handling equipment, and industrial robotics. It features a standard control panel with a single-line display and four keys, enabling error memory analysis, load default initialization, analog output configuration, and management of SERCOS interface transmission power. This module supports SERCOS interface master communication and includes options for encoding via IndraDyn/Hiperface/1 Vpp/TTL as well as HSF/RSF and EnDat 2.1/1 Vpp/TTL. The unit operates with a 9 W power requirement, utilizes a 24 V power supply, permits up to 6 A inrush current, and allows a maximum pulse width of 60 ms. The hardware supports up to 20 mounting and dismounting cycles by a qualified technician.

Technical Specifications

Product Type
Control Section

Design Family
CDB

Design Line
1

Control Panel
Standard

Plug Type
Non-Hot Plug

Interface
SERCOS

Safety Option
Starting Lockout

Firmware
To be ordered separately

Power Consumption
9 W

Inrush Current
6 A

Maximum Pulse Width
60 ms

Power Supply
24 V

Availability
Indramat USA

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CDB01.1C-SE-ENS-EN1-EN2-NNN-L1-S-NN-FW.

Exchange

Want to sell your CDB01.1C-SE-ENS-EN1-EN2-NNN-L1-S-NN-FW?
