R911306867 (CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW)

Name: R911306867 (CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW)
Brand: Indramat Drives
SKU: CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW
Price: 392.00 USD
Availability: InStock

CDB Control Units

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 5 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911306867 (CDB01.1C-PB-EN1-EN1-EN2-EN2-S1-S-NN-FW) from Rexroth Indramat serves as a control section in modular drive systems used in applications such as textile machinery, machine tools, printing, and packaging. It features a single configuration slot for safety technology, one serial interface, and supports PROFIBUS master communication. The device uses a connection cable with a diameter between 0.08 mm and 0.5 mm and requires terminating resistors at the first and last bus node. It is equipped with two status LEDs (green for operation, red for error). The onboard control panel enables diagnostics, state monitoring, analog output configuration, load default procedures, error memory access, and position data referencing. Supported encoder interfaces include HSF/RSF and EnDat 2.1/1Vpp/TLL. Electrical specifications are a 16 W power consumption, 5 A inrush current, maximum pulse width of 40 ms, and a 24 V supply requirement.
