R911307449 (CDB01.1C-SE-EN1-EN1-NNN-MA1-L1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN1-EN1-NNN-MA1-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911307449 (CDB01.1C-SE-EN1-EN1-NNN-MA1-L1-S-NN-FW) is an industrial controller featuring a CDB01.1 control section with standard control panel and SERCOS interface master communication. It supports two customizable analog outputs, one relay contact, and a single RS232 serial interface input. The unit operates with HSF/RSF encoder compatibility and includes a starting lockout for safety. It supports a pulse width limit of 60 ms and a SERCOS cycle time up to 1000 μs. Electrical requirements include 24 VDC nominal supply, 9W power consumption, and 6A inrush current. Mechanical dimensions are 49.5 mm (depth) x 103 mm (width) x 322.6 mm (height).

Technical Specifications

Pulse Width
60 milliseconds

SERCOS Cycle Time
1000 microseconds

Analog Outputs
2

Relay Contact
1

Control Panel
Standard

Communication
SERCOS interface master

Analog I/O Extension
Option 4

Safety Feature
L1 (starting lockout)

Digital Inputs
22

Digital Outputs
4

Velocity Control Range
250-500 microseconds

Current Control Range
125-1000 microseconds

Position Control Range
500-1000 microseconds

Power Consumption
9 W

Inrush Current
6 Amps

Input Voltage
24-volt direct current

RS232 Serial Interface Input
1

Physical Dimensions
49.5 mm x 103 mm x 322.6 mm
