R911307450 (CDB01.1C-SE-EN1-EN1-NNN-MEM-L1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN1-EN1-NNN-MEM-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911307450 (CDB01.1C-SE-EN1-EN1-NNN-MEM-L1-S-NN-FW) is a control section featuring a SERCOS interface master communication module, L1 safety functionality, and support for HSF/RSF encoders. This unit supports frequency adjustment between 2 kHz and 8 kHz in 2 kHz increments, and features a standard control panel, an encoder emulator, and a SERCOS cycle time of 1000 microseconds. It is configured with two analog outputs, one analog input, four digital outputs, and 22 digital inputs. The device supports both speed and position control, operates at 9 watts, and has a pulse width of 60 milliseconds. Firmware must be sourced separately. Proper operation requires adherence to specified environmental conditions and handling by trained personnel.

Technical Specifications

Frequency Range
2-8 kHz

Interface
SERCOS

Safety Option
L1

Encoders Option 1 and 2
HSF/RSF

Control Panel
Standard

SERCOS Cycle Time
1000 microseconds

Analog Outputs
2

Pulse Width
60 milliseconds

Operating Power
9 watts

Analog Inputs
1

Digital Outputs
4

Digital Inputs
22

Control Current
125 microsecond

Position Control Range
500-1000 microseconds

Speed Control Range
250-500 microseconds

Firmware
Must be ordered separately
