R911308118 (CDB01.1C-SE-ENS-ENS-EN1-EN1-L1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-ENS-EN1-EN1-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth control section R911308118 (CDB01.1C-SE-ENS-ENS-EN1-EN1-L1-S-NN-FW) is designed for integration with compatible power sections in drive control systems. The module features two EN and two EN1 optional modules, each EN1 module providing an average output voltage of 18.2V, peak output current of 70mA, and a minimum DC load resistance of 35 Ohms. Master communication is achieved via the SERCOS interface, and the control section supports encoder options including Indradyn, Hiperface, 1 Vpp, TLL, HSF, and RSF. It offers two digital inputs per IEC 61131, a multimedia card slot, and spring terminal connections for ferrule-free wiring. Each encoder optional module consumes 6W power.

Technical Specifications

Design Code
1

Usage
Industrial Environments

Application
Handling and Mounting Systems

Optional Modules
2 EN and 2 EN1

EN1 Modules Output Voltage
18.2V AC

EN1 Modules Output Current
70mA

EN1 Modules Load Resistance
35 Ohms Minimum

Digital Inputs
2 Type 3, Used as Probe, Rapid Inputs

Digital Outputs Adherence
IEC 61131 Specifications

Axes
Double

SERCOS Cycle Time
1,000μs Minimum

Use of Digital Inputs
2 as 1 Analog Voltage Input

Memory Card Slot
Present

Memory Card Variants Supported
2

Encoder Modules Power Consumption
6W Each

Connections
Wire Ends Without Ferrules Using Spring Terminals

Pulse Width
60ms Maximum

Packaging
Custom Military-Grade Packaging
