R911308280 (CDB01.1C-SE-EN1-EN1-EN2-NNN-NN-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN1-EN1-EN2-NNN-NN-S-NN-FW Series Image

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911308280 (CDB01.1C-SE-EN1-EN1-EN2-NNN-NN-S-NN-FW) is a control section engineered for Bosch Rexroth IndraDrive controllers, operating on a 24V DC supply. It features five module slots—four for function modules and one for a safety module. Encoder HSF/RSF modules are present in slots one and two, with an EnDat 2.1 encoder module in slot three. The unit incorporates a SERCOS master communication interface supporting data rates of 2/4 Mbps. Its dimensions are 322.6 x 49.5 x 103 mm, and it is suitable for vertical mounting. Power consumption totals 29 W, and recommended operating conditions are 0 to 40°C ambient temperature and installation altitudes between 0 and 1000 meters.

Technical Specifications

Product Type
Control Section for IndraDrive Controllers

Mounting
Vertical

Dimension
322.6 x 49.5 x 103 millimeters

Power Supply
24 Volts DC

Master Communication Interface
SERCOS

Data Rates
2/4 Mbps

Configurable From
Standard Control Panel

Unit Power Consumption
9 Watts

Power Consumption of Each Encoder Module
6 Watts

SERCOS Module Power Consumption
2 Watts

Total Device Power Consumption
29 Watts

Power Consumption with Standard Control Panel
1 Additional Watt

Recommended Ambient Conditions for Operation
0 to 40 degrees Celsius, 0 to 1000 meters
