R911308371 (CDB01.1C-SE-ENS-ENS-EN2-EN2-L1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-ENS-EN2-EN2-L1-S-NN-FW Series Image

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The CDB01.1C control section, MPN R911308371 (CDB01.1C-SE-ENS-ENS-EN2-EN2-L1-S-NN-FW), is designed for double-axis drive control in Rexroth IndraDrive systems. It features four integrated, configurable I/O channels and supports SERCOS fiber optic communication as master interface. The unit accommodates 12V encoder systems, with an encoder evaluation interface for 5V encoders, and provides encoder support for Indradyn, Hiperface, 1 Vpp, TLL, and EnDat 2.1. Switch frequencies are selectable at 2, 4, or 8 kHz, with a current control cycle time of 125 µs. A safety starting lockout is included. The device should not be mounted or dismounted more than 20 times, and is supplied in conductive packaging.

Technical Specifications

Design Type
1

Integrated I/Os
4

Interface Type
SERCOS

Encoder Systems Supply Voltage
12V

Encoder Evaluation Interface Voltage
5V

Switching Frequencies
2kHz, 4kHz, 8kHz

Current Control Cycle Time
125 microseconds

Safety Feature
Starting lockout technology

Mounting and Dismounting Limit
20 times

Storage
Conductive packaging

Control Method
Standard control panel

Firmware Compatibility
Yes

Global Shipping
Yes
