The Bosch Rexroth R911308564 (CDB01.1C-SE-EN1-EN1-NNN-MEM-S1-S-NN-FW) is a control section designed for integration with digital drive controllers. It features master communication via SERCOS Interface and supports two optional HSF/RSF encoder modules, each with 18.2VAC peak-to-peak or 8VDC supply voltage for HSF/RSF evaluation, connected through 15-pin female D-Sub interfaces. The unit includes an adaptable analog input, configurable as two digital inputs, and provides two Type 2 and Type 3 digital probe inputs supporting voltages from -3V to 30V with nonlinear input resistance depending on voltage level. Digital outputs are user-configurable, and an open relay contact is present. Connection for programming, parameterization, or diagnostics is supported via RS 232 serial interface using either spring or screw terminals. The device complies with IEC 61131 standards.

Technical Specifications

Analog Input Type
IEC 61131

Analog Input Functionality
Also Functions as Two Digital Inputs

Optional Modules
Two EN1

Peak-to-Peak Voltage
18.2VAC

Supply Voltage
8VDC

Connector Type
Female D-Sub Connectors with 15 Poles

Digital Inputs
Two of Each Type 2 and Type 3

Probe Inputs Voltage Rating
-3V to 30V

Axes
Two

Configuration Slots
Two

Control Panel Compatibility
No

Digital Outputs Activation
High-Side Switches

Relay Contact
Normally Open Type

Backup Support
One Year

Serial Interface
RS 232

Connector for RS 232
Female Eight-Pole MiniDin

Base Connector
Spring Terminals or Screw Terminal Blocks

Power Supply Terminals
0V and 24V
