R911309011 (CDB01.1C-SE-EN1-EN1-NNN-MA1-S1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN1-EN1-NNN-MA1-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911309011 (CDB01.1C-SE-EN1-EN1-NNN-MA1-S1-S-NN-FW) is a control section designed for drive controllers, with physical dimensions of 322.6 mm length, 241 mm width, and 49.5 mm depth. It includes a single analog input, supports a switching frequency range of 2 to 8 kHz, and utilizes the SERCOS interface for communication. Both option 1 and option 2 encoder ports are configured for HSF/RSF encoder compatibility, while option 3 is not equipped. This model is equipped with S1 safety technology and an operator's panel, supports analog I/O extension, and conforms to IEC standards. Installation and operation should follow the user manual to ensure correct performance within specified ambient temperature and humidity limits, using defined accessories and parts.

Technical Specifications

Product Type
Components

Physical Dimensions
322.6 mm x 241 mm x 49.5 mm

Analog Input
Single

Pulse Width
Up to 60 milliseconds

Ventilation Spacing
Required if used in group

Encoder Option
HSF/RSF Encoder in both option 1 and 2

Compliance
IEC standards

Communication Interface
SERCOS Interface

Extra features
Standard Operators Panel, Analog I/O extension

Ambient Temperature
Should not exceed maximum permitted temperature

Relative Humidity
Should not exceed 90%

Switching Frequency
2 to 8 kHz

Safety Features
S1 safety technology

Usage Conditions
As specified in product user manual

Additional Accessory Compatibility
As specified in product user manual
