R911309013 (CDB01.1C-SE-EN1-EN1-EN2-MEM-S1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN1-EN1-EN2-MEM-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911309013 (CDB01.1C-SE-EN1-EN1-EN2-MEM-S1-S-NN-FW) is a digital control section for IndraDrive systems, engineered for precise regulation of industrial motors. This module forms part of a two-component assembly, working in conjunction with the power section which provides connections for mains voltage, motor, DC bus, 24V supply, and module bus. The unit includes a basic control board with five plug-in modules: Safety Technology I/O, two HSF/RSF encoder modules, one EnDat 2.1/1Vpp/TLL encoder module, and an encoder emulation module. Configuration is enabled via a basic control panel. The master communication protocol is the SERCOS interface, and firmware must be selected separately.

Technical Specifications

Product Type
IndraDrive Controller

Components
Power Section, Control Section

Control Section Category
Basic Universal

Connections
Mains Voltage, Motor, 24 Volts, DC Bus, Module Bus

Removal/Mount Limit
20

Plug-in Modules
5

Encoder Module Types
HSF/RSF, Encoder Emulation, EnDat 2.1

Configurable
Yes, From Standard Control Panel

Firmware
Ordered Separately

Master Communication Interface
SERCOS

Shipping
Global
