R911309014 (CDB01.1C-SE-EN1-EN1-EN2-MEM-NN-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN1-EN1-EN2-MEM-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The control section with MPN R911309014 (CDB01.1C-SE-EN1-EN1-EN2-MEM-NN-S-NN-FW) is engineered for integration within the IndraDrive family of drive controllers. Its modular hardware configuration consists of a base unit with five slots: four are populated with two HSF/RSF encoder modules, an encoder emulation module, and an EnDat 2.1 encoder module; the remaining slot allows for the addition of a safety module. The device supports SERCOS communication and provides an RS-232 interface for connection with computers or terminals. Physical dimensions are 322.6 x 103 x 49.5 mm. Operation and modification of the unit should be performed by qualified personnel only.

Technical Specifications

Product Type
Control Section

Architecture
Modular

Slots Number
5

Pre-installed Modules Number
4

Vacant Slots for a Safety Module
1

Dimensions
322.6 x 103 x 49.5 millimeters

RS-232 interface
Yes

Current Control Cycle Time
125 microseconds

Velocity Control Cycle Time
250 or 500 microseconds

Position Control Cycle Time
500 or 1000 microseconds

SERCOS Cycle Time
1000 microseconds

Supported Switching Frequencies
2 kilohertz, 4 kilohertz, 8 kilohertz

Communication Support
SERCOS master communication

Ambient Temperature
0 to 40 degrees Celsius

Installation
By Qualified Trained Personnel Only

Global Shipment
Yes
