R911309541 (CDB01.1C-SE-ENS-EN1-NNN-NNN-NN-S-NN-FW)

Name: R911309541 (CDB01.1C-SE-ENS-EN1-NNN-NNN-NN-S-NN-FW)
Brand: Indramat Drives
SKU: CDB01.1C-SE-ENS-EN1-NNN-NNN-NN-S-NN-FW
Price: 726.00 USD
Availability: InStock

CDB Control Units

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 29 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911309541 (CDB01.1C-SE-ENS-EN1-NNN-NNN-NN-S-NN-FW) is a configurable control section used within Indramat drive controllers, designed to interface with a power module and manage two axes. This unit provides a single configuration slot, safety technology, 5 to 8 digital inputs, up to three digital outputs, and a normally open relay contact. Supported switching frequencies are 2 kHz, 4 kHz, or 8 kHz. The control section features a SERCOS interface for master communication and supports encoder options including IndraDyn, Hiperface, 1 Vpp, and TTL. It includes a standard control panel for parameter adjustment and error diagnostics. Key electrical data for the R911309541 are 9 W power consumption, maximum pulse width of 60 ms, and a 6 A inrush current. Installation and removal must be performed by personnel trained in Rexroth Indramat systems to avoid damage.
