R911309978 (CDB01.1C-SE-ENS-ENS-NNN-MEM-L1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-ENS-NNN-MEM-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 16 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911309978 (CDB01.1C-SE-ENS-ENS-NNN-MEM-L1-S-NN-FW) is a control section from Bosch Rexroth's CDB product line, designed for integration within a drive controller system. It features a 2W SERCOS fiber optic interface for master communication, allowing connection of drive controllers to higher-level control units. The unit measures 322.6 x 103 x 49.5 mm and includes both digital and analog I/O, a memory card slot in connector X7, and a 'Normally Open' relay contact. Four combinable I/O channels are provided, with connections for encoder signals (Indradyn, Hiperface, 1 Vpp, TTL) on two channels. The minimum SERCOS cycle time is 1,000µs. An H1 interface supports connection to a control panel. Proper handling is required to avoid damage due to heat or mechanical stress. Firmware is not included and must be sourced separately; refer to the device manual for correct installation and operation.

Technical Specifications

Product Group
CDB

Communication Interface
SERCOS

Power Consumption of Interface
2W

Dimension
322.6 x 103 x 49.5mm

Memory Card Slot
Available in X7 Connector

Inputs/Outputs
Digital and Analog

Front Interface
H1

Protection
Fitted with Protective Diode

Plug-in Actions
Limited

Relay Contact
One Normally Open

Firmware
Purchased Separately

Combined Inputs/Outputs
Four, Configurable as Digital Input or Output

Minimum SERCOS Cycle Time
1,000µs

Mounting Instructions
Not for Frequent Mounting/Dismounting

Usage
Industrial Environments

Required Prior Knowledge
Understanding of the Associated Documentation

Shipping Availability
Global
