R911310273 (CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 40 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911310273 (CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW) is a dual-axis CDB series control section in the Bosch Rexroth IndraDrive system, designed for integration in automated equipment such as machine tools and packaging machines. It features three encoder evaluation interfaces supporting 5V encoder systems including 5V-TTL, Sin-Cos with EnDat 2.1 and sense lines, and Sin-Cos with reference track. Communication is managed via a SERCOS master interface, with data transfer over fiber optic connections. The unit supports user navigation for drive addressing, error diagnosis, position referencing, and SERCOS configuration. Safety functions provided include safety-related standstill, drive interlock, and direction of motion. Inrush current is rated at 6A with a maximum pulse width of 60 ms. Firmware must be installed separately.

Technical Specifications

Product
Rexroth IndraDrive Drive Controller

Type
Double-Axis

Encoder Interfaces
Three

Supply Voltage
5V

Communication Module
SERCOS master

Fiber Optics Cables
Not included (Can be ordered separately)

Control Panel
Standard

Safety Options
Safety Technology I/O

Firmware
Not included (Can be ordered separately)

Typical Inrush Current
6A

Maximum Pulse Width Value
60ms

Shipping
Global.

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW.

Exchange

Want to sell your CDB01.1C-SE-EN2-EN2-EN2-NNN-S1-S-NN-FW?
