The Bosch Rexroth control section R911313868 (CDB01.1C-PB-ENS-ENS-NNN-MEM-NN-S-NN-FW) is designed for use in automation systems, supporting PROFIBUS master communication. It operates at 24VDC with a maximum power consumption of 9W. The unit incorporates a single analog input, dual analog outputs, and supports encoder interfaces including Indradyn, Hiperface, 1 Vpp, and TTL. There is no installed module at the X8.1 slot; instead, a MEM module is connected via a 15-pole D-sub interface, requiring no external power supply. It accommodates PFM02.1 multimedia cards for parameter management. Firmware is not included and must be acquired separately.

Technical Specifications

Safety Mechanism
None

Inputs
1 Analog

Outputs
2 Analog

Power Consumption
9W at 24VDC

Multimedia Card Compatibility
PFM02.1

Line Code
01

Optional Module at X8.1 Point
None

MEM Optional Module
Used for signal emulation

MEM Module Power Supply
None needed

Connector Type
D-Sub, 15 Poles

Connecting Wire Range
0.25mm2 - 0.5mm2

Firmware
Procured separately

Frequent Power Connection/Disconnection
Can cause damage

Package type
Conductive

Use
Non-residential

Operation
After reading provided documentation

Transportation
Custom military grade packaging
