CDB Drive Controllers | Indramat Drives
R911313869 (CDB01.1C-SE-ENS-EN1-EN2-NNN-S1-S-NN-FW)
Request a quote
Description
R911313869 is part of the CDB Drive Controllers Series by Indramat Drives.
Specs
Design Code: 1
Analog Input: 1
Analog Output: 2
Supported Multimedia Card Variants: PFM02.1
Digital Input Type: 1
Input Voltage Range: -3V to 30V
Input Current Range: 2mA to 5mA
Maximum Attachment and Detachment Times: 20
Axes: 2
Interface Type: RS 232
Node: 1
Minimum Transmission Rate: 9.6kBaud
Maximum Transmission Rate: 115kBaud
Engineering Interface Inputs: 2
Engineering Interface Outputs: 2
Ethernet Compatibility: 100Base-TX according to IEEE 802.3u
Power Consumption: 9W at 24VDC
Backup Support: 1 Year
Power Supply for Isolated Inputs/Outputs: Separate Power Supply at X31 and X32
Connection Point Types: Screw Terminal Blocks and Spring Terminals
Environmental Impact: None
Hazardous Substances: None
Operation Temperature: Normal
Transportation Partners: USPS and UPS.
Analog Input: 1
Analog Output: 2
Supported Multimedia Card Variants: PFM02.1
Digital Input Type: 1
Input Voltage Range: -3V to 30V
Input Current Range: 2mA to 5mA
Maximum Attachment and Detachment Times: 20
Axes: 2
Interface Type: RS 232
Node: 1
Minimum Transmission Rate: 9.6kBaud
Maximum Transmission Rate: 115kBaud
Engineering Interface Inputs: 2
Engineering Interface Outputs: 2
Ethernet Compatibility: 100Base-TX according to IEEE 802.3u
Power Consumption: 9W at 24VDC
Backup Support: 1 Year
Power Supply for Isolated Inputs/Outputs: Separate Power Supply at X31 and X32
Connection Point Types: Screw Terminal Blocks and Spring Terminals
Environmental Impact: None
Hazardous Substances: None
Operation Temperature: Normal
Transportation Partners: USPS and UPS.
Shipping
Call For Quote | Warranty | Shipping | Repairs | Exchange |
|---|---|---|---|
| 1 Year Indramat USA Warranty included | Worldwide shipping via UPS and Fedex | We offer repair service for the R911313869 in 10 Days. | Exchange credit for your defective unit available. |
