R911315100 (CDB01.1C-SE-EN2-EN2-EN2-EN2-L1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-EN2-EN2-EN2-EN2-L1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch R911315100 (CDB01.1C-SE-EN2-EN2-EN2-EN2-L1-S-NN-FW) is a modular control section designed for double-axis operation, featuring five hardware module slots. Slots 1 to 4 are equipped with pre-installed EnDat 2.1 encoder modules, while slot 5 contains a starting lockout module. It incorporates a SERCOS master communication interface and provides an integrated control panel with display and keypad for command input and status monitoring. The unit offers RS-232 serial connectivity, operates on a 24 VDC supply, and utilizes convection cooling. Recommended operating parameters include a temperature range of 0-40°C and an installation altitude up to 1000 meters above sea level. Implementation and adjustment should be performed by qualified personnel.

Technical Specifications

Configurable
Yes

Hardware Module
5 slots

Encoder Modules
EnDat 2.1

Safety Module
Starting lockout

Master Communication
SERCOS

Standard Control Panel
Yes

Double-Axis Applications
Yes

Integrated Interface
RS-232 serial interface

Mounting
Vertical

Power supply
24 Volts DC

Cooling Method
Convection

Recommended Operation Temperature
0 to 40 degrees Celsius

Recommended Operation Elevation
0 to 1000 meters

Handled by
Qualified Personnel

Global Shipping
Yes
