R911316577 (CDB01.1C-SE-ENS-EN2-EN2-NNN-NN-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN2-EN2-NNN-NN-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911316577 (CDB01.1C-SE-ENS-EN2-EN2-NNN-NN-S-NN-FW) is a control section designed for automation systems, featuring a standalone RS232 serial interface, analog input, and two analog outputs. It operates from a 24 V DC supply and draws 9 W, with a maximum inrush current of 6 A. The unit supports master communication via SERCOS Interface and includes encoder options such as Indradyn/Hiperface/1 Vpp/TLL and EnDat 2.1/1Vpp/TLL. It features a standard control panel, 18 to 22 digital inputs, four configurable digital outputs, a relay contact, and two touch probe ports. The device integrates cycle time functions for velocity, current, and position control, and is compatible with stranded wire diameters from 0.75 mm to 1.5 mm.

Technical Specifications

Interface
RS232 serial interface

Power Source
24-watt DC

Power Consumption
9w

Inrush Current
6 Amp

Minimum SERCOS Cycle Period
1000 milliseconds

Maximum Pulse Width
60 milliseconds

Analog Inputs
Single

Analog Outputs
Two

Standard Control Panel
Included

Digital Inputs
18 to 22

Cycle Time Function
Yes

Digital Outputs
Four Customizable

Relay Contact
One

Touch Probe Slots
Two

Construction Material
Stranded Wire

Wire Diameter
0.75 to 1.50 mm

Intended Application
Industrial Use

Option 1 Encoder
indraDyn/hiperface encoder

Communication Interface
SERCOS interface master

Option 2 and 3 Encoders
EnDat2.1 encoders

Global Shipping
Available
