The Bosch Rexroth R911318146 (CDB01.1C-SE-ENS-ENS-EN2-MEM-NN-S-NN-FW) is a control unit engineered for managing double-axis drives. The CDB01.1 control section measures 322.5 mm x 103 mm x 49.5 mm and features 14 digital input ports, 4 configurable as touch probes. The unit supports an adjustable PWM frequency from 2 kHz to 16 kHz in 2 kHz increments and is equipped with 2 x 10 V analog inputs and outputs, 1 relay output, 8 customizable digital ports, and 2 Ethernet ports. Encoder emulation is available on both interface 1 and 2. It also incorporates a single-line LED display for status and diagnostics, with a memory card-compatible control panel. Supported encoder interfaces include Indradyn, Hiperface, 1 Vpp, TLL, and EnDat 2.1. Master communication is provided via SERCOS interface.

Technical Specifications

Product Name
Bosch Rexroth Control Unit

Dimensions
322.5mm x 103mm x 49.5mm

Digital Input Ports
14

Touch Probe Ports
4

PWM Frequency Adjustment
2 kHz to 16 kHz

Analog Inputs and Outputs
2 x 10V

Relay Output
1

Configurable Digital Ports
8

Ethernet Ports
2 (X24 and X25)

Encoder Emulation Features
Present at Interface 1 and Interface 2

Control Panel Interface
H1

Control Panel Display
Single-line LED display

Double-Axis Drive
Supported

Delivery
Worldwide

Product Use
Suitable for high-end applications.
