R911318160 (CDB01.1C-SE-ENS-EN2-EN2-EN2-S1-S-NN-FW)

CDB Control Units

CDB01.1C-SE-ENS-EN2-EN2-EN2-S1-S-NN-FW Series Image

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911318160 (CDB01.1C-SE-ENS-EN2-EN2-EN2-S1-S-NN-FW) is a Bosch Rexroth control section with a power consumption of 9 W and incorporates one analog input along with four configurable digital outputs. The device features a standard control panel and provides a SERCOS interface with a cycle period of 1000 μs. Pulse width is 60 ms. The unit supports 22 digital inputs, with a speed control range of 250–500 μs and a position control range of 500–1000 μs. Integrated options include safety technology I/O (S1) and multiple encoder options—IndraDyn/Hiperface, EnDat 2.1, and 1 Vpp/TTL. Firmware is not pre-installed and must be procured separately.

Technical Specifications

Power Consumption
9 Watts

Analog Input
1

Digital Outputs
4

SERCOS Cycle Period
1000 Microseconds

Pulse Width
60 Milliseconds

Analog Output
2

Encoder Option 1
IndraDyn/Hiperface

Safety Option
S1

PWM Frequency
2 kHz to 8 kHz

Communication Module
SERCOS interface master

Interface
Serial RS232

Encoder Option 2, 3 and 4
EnDat2.1/1 Vpp/TTL

Digital Inputs
22

Control Current
125 Microseconds

Speed Control Range
250-500 Microseconds

Position Control Range
500-1000 Microseconds

Availability
Global
